ALW-PRO Heavy Duty Infrared Therapy Lamp – 1000W / 1250W | Dual Chip Red & IR | Touch Control with Timer & Pulse Dimming | 30° Lens | AC85–265V | Goggles Included | for Skin Care | US / EU / UK / AU Plug
1000 / 1250 pcs 5W LED (660nm Red + 850nm Near-Infrared)
-
Dual-Wavelength Red & Near-Infrared Output (660nm + 850nm, 1:1 Ratio)
High-performance 5W single-core LEDs deliver a balanced combination of 660nm red light and 850nm near-infrared light. Available in 1000 / 1250 LED configurations for versatile therapy applications from skin-level care to deep tissue recovery. -
High Power Output with Optional Pulse Dimming
Total power options: 1000W / 1250W (±5%). Adjustable brightness and pulsed light modes allow customization of intensity and therapy rhythm. -
Multiple Lighting Modes & Built-in Touch Timer
Supports three selectable light modes:
– 660nm red light only
– 850nm near-infrared light only
– Red & near-infrared combined mode
Irradiance reaches over 170–200 mW/cm² at 6 inches (model dependent).
Integrated touchscreen timer allows preset session durations for safe and convenient daily use. -
Flexible Installation: Hanging or Mobile Stand
Supports hanging installation or optional floor-standing mobile base with wheels, suitable for home, gym, studio, clinic, or wellness environments. -
Complete Accessory Kit
Supplied with protective goggles, power cable, hanging rope, hooks, and lifting ropes — ready for immediate use.
Package Included:
| Power | Plug Type | Base Option | Package Included |
| 1000W | US/EU/UK/AU Plug | Without Base | Panel + Hanging Kit + Goggles |
| 1000W | US/EU/UK/AU Plug | With Mobile Base | Panel + Mobile Base + Hanging Kit + Goggles |
| 1000W | US/EU/UK/AU Plug | With Electrical Mobile Stand | Panel + Electrical Mobile Stand + Hanging Kit + Goggles |
| 1250W | US/EU/UK/AU Plug | Without Base | Panel + Hanging Kit + Goggles |
| 1250W | US/EU/UK/AU Plug | With Mobile Base | Panel + Mobile Base + Hanging Kit + Goggles |
| 1250W | US/EU/UK/AU Plug | With Electrical Mobile Stand | Panel + Electrical Mobile Stand + Hanging Kit + Goggles |
Specification:
| Item | Specification | |
| Model | AL-PRO4000 | AL-PRO5000 |
| Light Source | 5W Single-Core LED (Simulated Lumen) | |
| Wavelength | 660nm Red + 850nm Near-Infrared | |
| LED Quantity | 800 pcs | 1008 pcs |
| Switch System | Dual-Mode | |
| Timer Function | Yes (Touchscreen Control) | |
| Actual Power | 1000W ±5% | 1250W ±5% |
| Input Voltage | AC 85–265V, 50–60Hz | |
| Driver Power Supply | Isolated Constant Current | |
| Lens Angle | 30° | 30° |
| Housing Material | Alloy, Sandblasted White Finish | |
| Panel Dimensions | 1625 × 480 × 70 mm | 1830 × 530 × 70 mm |
| Standard Accessories | Power Cord, Suspension Rope, Hooks, Protective Goggles | |
| Unit Packaging Dimensions | 177 × 58 × 19 cm | 190 × 60 × 20 cm |
| Net Weight | 32 KGS | 38 KGS |
| Gross Weight | 35 KGS (Including Base) | 42 KGS (Including Base) |
Treatment
Distance: 6–18 inches
Treatment Time: 2–20 minutes depending on distance and goals
Frequency: Daily
DOWNLOAD
1. User Manual
2. CE EMC01
3. CE EMC02
4. EMC TEST REPORT
5. FCC SDOC
6. SAFETY TEST REPORT
7. FCC TEST REPORT
Product Reference Images (without Base)
1000W Infrared Therapy Lamp
1000 pcs 5W LEDs – high-output full-body infrared therapy
1250W Infrared Therapy Lamp
1250 pcs 5W LEDs – maximum power for deep tissue & professional use
Product Reference Images (with Mobile Base)
Product Reference Images (Electrical Mobile Stand)
| The electrical mobile stand support with remote control for height adjustment and manual adjustment for 360-degree rotation of the panel. Adjustable height range: 90-140cm. G.W. 20KGS，Packing Size: 1030*320*230mm |
