BXRC-65E4001-C-84-SE Bridgelux Gen8 Vero SE 18 LED Array – 6391 lumen 6500K-Fast Shipping

Description

Bridgelux Vero SE 29 LED Array chip on board (CoB), 16474 lumen, 80 CRI min, 4000K Neutral White Color Temperature, 3-Step MacAdam Ellipse

Order Separately – Molex Pico Wire Harness for Bridgelux Vero 10/13/18/29 Arrays

Bridgelux Vero SE 29 LED Array Chip on Board 16474 Lumen 4000K

Vero SE 29 Series 4000K 80 CRI min 16474 lm 66.7V 3 SDCM Neutral White LED Array

Vero SE Series is a revolutionary light source system that integrates Bridgeluxs 8th generation COB technology with poke-in connectivity enabling solder-free installation

Typical 190 lm/W typical

Dual poke-in connectivity

49.20mm side-to-side, flat height of 3.60mm

Viewing Angle: 120°

Typical Drive Current: 1300mA

Spec Sheets

BXRC-40E10K0-C-83-SE Spec Sheet
