LNE-36V320WDAA Delta Constant-Power LED Driver – 320W Dimming-Fast Shipping

Description

Delta LNE-36V320WDAA Configurable Constant Power (Adjustable current and voltage) 320W LED Driver, Dimming, 90-305Vac input, adjustable 36Vdc and 8900mA output.

Delta 320W 8900mA / 36VDC Adjustable Dimming LED Driver

Programmable, Enabling Hundreds of Configurations – potentiometers to adjust output voltage & constant current (CC) level

Output Current Range: 4450-8900mA

Output Voltage Range: 18-36Vdc in CC mode and 33-40Vdc in CV mode

Dimming Controls: Analog (0-10V), PWM

IP67 and UL Dry/Damp Location

High surge immunity (common mode: 6kV, differential mode: 4kV)
