Description
LSP10480S LED Driver Surge Protector, 20kA Max / 10kA Nominal Surge Protection, 480V Input, Series Wiring, IP66
LSP10 Series LED Driver Surge Protectors
The Littelfuse LSP10 thermally protected Surge Protective Device is a self-protected device which is specially designed to be used in outdoor and commercial LED lighting fixtures for transient over voltage protection.
Protection for LED drivers capable of operating at 480V input voltage or with universal input range
Main Voltage: 480V
Continuous Max Voltage Range: 150VAC – 510Vdc
IP66 rated, dust-tight and water resistant
85ºC max surface temp rating
Parallel or Series connected options designated by P or S at end of model number
Spec Sheets
Littelfuse LSP10480S Specs
Littelfuse LED Surge Protection Installation Guide
