Description
INVENTRONICS Constant Current LED Driver, 42W Max Power Output, Universal 120-277V Input, Fixed Output Current 1400mA, 15-30Vdc Output Voltage, Analog 0-10V Dimming, Waterproof (IP66) and UL Damp Location
DISCONTINUED by Manufacturer – please review candidate replacement and enter required Output Current setting here: Candidate Replacement
INVENTRONICS LED Drivers 42W 1400mA Constant Current
Every LED array or fixture requires a driver to provide efficient power. At BallastShop we offer a wide array drivers to meet your power output and dimming requirements of virtually any LED in the marketplace.
Total Power: 42 Watts
Fixed Current Output: 1400mA
Input Voltage: 90-305 VAC
Waterproof (IP66) and UL Damp Location
Class 2
Efficiency 85%
Operating temperature range: -20°C to 85°C
Polycarbonate Housing
0 – 10V Dimmable (Compatible with Passive Dimmers)
Constant Current Output
Active Power Factor Correction
All-Around Protection: OVP, SCP and Open Lamp Protection
Spec Sheets
LUC-042D140DSP Spec Sheet
