XJ180C090V285VSF2 Advance Xitanium SR DuraVolt Programmable LED Driver – 180W 700mA Sensor-Ready-Fast Shipping

Description

Advance Xitanium DuraVolt SR (D4i certified) Constant Current LED Driver, 180W Max Power Output, 277-480V Input, SimpleSet Programmable Output Current 100mA to 900mA (Factory Default 700mA), Output Voltage 100-285V, Dali 2-wire Dimming, Auxiliary Power

Advance Xitanium DuraVolt 180W 700mA Programmable LED Power Supply

Advance Xitanium DuraVolt LED drivers protect lighting systems from poor power quality issues like voltage swells, dirty power, and loss of neutralsproblems that standard surge protectors (SPDs) can’t handle. This makes them ideal for places with high electrical demands, like factories with heavy machinery, or areas with aging power grids where power quality is less reliable.

Total Max Output Power: 180 Watts

Input Voltage: 277-480 VAC

Output Voltage Range: 100-285V

Output Current: Programmable 100mA to 900mA (Factory Default 700A) via SimpleSet

UL Damp and Dry and HL

Dimming via DALI 2-wire. Logarithmic curve is default. 10% minimum default setting.

Operating Temp Range: -40 to +55 °C

Class 1 and 2 Wiring

6kV combi-wave surge rating to comply with ANSI C82.77-5 CAT C

Available in non-aux, aux, and SR versions

Auxiliary Power: 3W 24Vdc

Additional SimpleSet Programmable Features: Dimming Curve, Dimming Range, Adjustable Startup Time, Constant Lumen over Lifetime, Diagnostics, Main Limit Protection, Advanced Internal Thermal Protection, Dynadimmer

Advance Xitanium DuraVolt XJ180C090V285VSF2 Specs

Advance Xitanium DuraVolt Brochure
